Choice of Light, Standard & Heavy Duty Racking.
-
Pallet Racking ideal for Commercial and Industrial use.
-
Warehousing, Storerooms, Despatch areas etc.
-
Custom made units manufactured to order as per your load requirements.
-
The following Standard Sizes are kept on the floor as stock items.
-
Easily adjustable levels per your load specifications
-
Epoxy Powder Coated
-
Wooden & Steel Decking available
3300 mm 600 mm
3300 mm 750 mm
3300 mm 900 mm
3300 mm 1050 mm
3300 mm 1200 mm
3600 mm 600 mm
3600 mm 750 mm
3600 mm 900 mm
3600 mm 1050 mm
3600 mm 1200 mm
3900 mm 600 mm
3900 mm 750 mm
3900 mm 900 mm
3900 mm 1050 mm
3900 mm 1200 mm
4200 mm 600 mm
4200 mm 750 mm
4200 mm 900 mm
4200 mm 1050 mm
4200 mm 1200 mm
4500 mm 600 mm
4500 mm 750 mm
4500 mm 900 mm
4500 mm 1050 mm
4500 mm 1200 mm
4800 mm 600 mm
4800 mm 750 mm
4800 mm 900 mm
4800 mm 1050 mm
4800 mm 1200 mm
5100 mm 600 mm
5100 mm 750 mm
5100 mm 900 mm
5100 mm 1050 mm
5100 mm 1200 mm
5400 mm 600 mm
5400 mm 750 mm
5400 mm 900 mm
5400 mm 1050 mm
5400 mm 1200 mm
5700 mm 600 mm
5700 mm 750 mm
5700 mm 900 mm
5700 mm 1050 mm
5700 mm 1200 mm
6000 mm 600 mm
6000 mm 750 mm
6000 mm 900 mm
6000 mm 1050 mm
6000 mm 1200 mm
6300 mm 600 mm
6300 mm 750 mm
6300 mm 900 mm
6300 mm 1050 mm
6300 mm 1200 mm
6600 mm 600 mm
6600 mm 750 mm
6600 mm 900 mm
6600 mm 1050 mm
6600 mm 1200 mm
6900 mm 600 mm
6900 mm 750 mm
6900 mm 900 mm
6900 mm 1050 mm
6900 mm 1200 mm
7200 mm 600 mm
7200 mm 750 mm
7200 mm 900 mm
7200 mm 1050 mm
7200 mm 1200 mm
7500 mm 600 mm
7500 mm 750 mm
7500 mm 900 mm
7500 mm 1050 mm
7500 mm 1200 mm
7800 mm 600 mm
7800 mm 750 mm
7800 mm 900 mm
7800 mm 1050 mm
7800 mm 1200 mm
.jpg)
End Frame Sizes
End Frame Sizes
Height mm
Height mm
Depth mm
Depth mm
900 mm 600 mm
900 mm 750 mm
900 mm 900 mm
900 mm 1050 mm
900 mm 1200 mm
1200 mm 600 mm
1200 mm 750 mm
1200 mm 900 mm
1200 mm 1050 mm
1200 mm 1200 mm
1500 mm 600 mm
1500 mm 750 mm
1500 mm 900 mm
1500 mm 1050 mm
1500 mm 1200 mm
1800 mm 600 mm
1800 mm 750 mm
1800 mm 900 mm
1800 mm 1050 mm
1800 mm 1200 mm
2100 mm 600 mm
2100 mm 750 mm
2100 mm 900 mm
2100 mm 1050 mm
2100 mm 1200 mm
2400 mm 600 mm
2400 mm 750 mm
2400 mm 900 mm
2400 mm 1050 mm
2400 mm 1200 mm
2700 mm 600 mm
2700 mm 750 mm
2700 mm 900 mm
2700 mm 1050 mm
2700 mm 1200 mm
3000 mm 600 mm
3000 mm 750 mm
3000 mm 900 mm
3000 mm 1050 mm
3000 mm 1200 mm
Beam Lengths (Boxed Beam)
76 x 50 1500 mm 2460 kg
76 x 50 1800 mm 2060 kg
76 x 50 2100 mm 1740 kg
76 x 50 2400 mm 1550 kg
76 x 50 2700 mm 1340 kg
76 x 50 3000 mm 1090 kg
100 x 50 1500 mm 3820 kg
100 x 50 1800 mm 2950 kg
100 x 50 2100 mm 2450 kg
100 x 50 2400 mm 2260 kg
100 x 50 2700 mm 1920 kg
100 x 50 3000 mm 1740 kg
100 x 50 3300 mm 1590 kg
100 x 50 3600 mm 1460 kg
125 x 50 1500 mm 4000 kg
125 x 50 1800 mm 3910 kg
125 x 50 2100 mm 3340 kg
125 x 50 2400 mm 2710 kg
125 x 50 2700 mm 2390 kg
125 x 50 3000 mm 2210 kg
125 x 50 3300 mm 1980 kg
125 x 50 3600 mm 1710 kg
150 x 50 1500 mm 4500 kg
150 x 50 1800 mm 4500 kg
150 x 50 2100 mm 4350 kg
150 x 50 2400 mm 4220 kg
150 x 50 2700 mm 3720 kg
150 x 50 3000 mm 3380 kg
150 x 50 3300 mm 3020 kg
150 x 50 3600 mm 2720 kg
150 x 50 3900 mm 2490 kg
Boxed Beam Size
Size (Length)
Load Capacity per pair
Each
Per Pair
Wooden Decking
Locking Pins
Post protectors
.jpg)
.jpg)
Wooden Decking, Post Protectors & Locking Pins will be quoted on as per order as many options are available to suit your specific specifications.
Important Safety Information:
Please Note:
All our Structural & Rack Supported Mezzanine Structures conform to the Technical Specifications of the manufacturer, which is in accordance with the S.E.M.A. code of practice.
